Mapping bundle

Precision mapping even in challenging environments

Mobile mapping can be challenging if you’re moving through different environments synchronising data from multiple sensors.

With this bundle you can georeference data from another sensor, such as camera and ground-penetrating radar, which can be used to improve positioning data in harsh GNSS environments.

This bundle is designed for mobile mapping setups that do not include LiDAR. For surveyors using LiDAR, our LiDAR Mapping Bundle provides the additional capabilities to georeference LiDAR data.

Get the mapping bundle

OXTS

Mapping bundle

Mapping bundle optimises your OXTS GNSS/INS with the following features:

PTP

Enables operation as a PTP master or slave/client in a network using the PTP IEEE 1588-2008 standard.

(code #12)

gx/ix GNSS Tight-Coupling

Enables the use of gx/ix GNSS tight-coupling engine up to integer position mode (~1cm accuracy) in real time and post-process.

(code #21,22, 61)

Raw Data Streaming

Enables real time streaming of raw data (RD) files for logging on an external device.

(code #34)

Ethernet Logging

Enables logging of real time NCOM and PCAP sensor data on the device via Ethernet.

(code #52)

gPTP

Enables operation as a gPTP master or slave/client in a network using the IEEE 802.1AS or AUTOSAR standards.

(code #64)

Note that external power is required to use the highest-grade GNSS antenna that OXTS offers (VEXXIS 850) with the xNAV650, AV200 and RT1003v2.

Talk to us about customising your bundle

Optimise and customise

If these feature bundles don’t give you quite what you need, you can customise them with specific features – or build your own feature bundle from the ground up. To do this, click below to get in touch and we’ll help you build your custom bundle.
